36 Inch Vamp Machine

This series adopts digital, high-speed rotary, high roller motor, motor needle, color change, long pin technology, realizes the knitting needle, and pick out your needle hole, and other regular pattern knitting, knitting basic knitting (Siping, single-sided etc.), no color the rules of jacquard, kraepelini other kinds of organization, and the performance is stable, efficiency is greatly improved.
This series of machines with a single head dual system. Digital technology is used to realize the needle turning, lifting and weaving actions of the flat knitting machine, and the scissors clip device and the bottom lifting device can be selected. high roller system, hold position closer to the needle plate tooth mouth, ensure to provide high quality control of the fabric cloth.

Product introduction:

Needle distance: 14G

Weaving range: 36, 52, 72 (inches)

Weaving speed: 24 segment selection, the highest speed of 1.2m/s, using AC servo motor control, servo motor using precise feedback control and combined with high-speed computing ability of digital signal processor (DSP), control IGBT to produce accurate current output;

Knitting system: single machine head dual system

The function of knitting needle, hanging head, pick holes, jacquard, intarsia, Ming received needle, dark closed needle, and other regular pattern knitting;

KS: displacement controlled by AC servo motor, move the needle range up to 2 inches, and with fine adjustment function;

Probe warning system: accurate position infrared probe alarm

Read needle signal: Advanced encoder read needle

Turn the needle function: Triangle compound design, single / double coordination can be single or simultaneous turn needle, also can be a system of weaving, to achieve efficient production;

Coil density: stepper motor control, 24 segment density selection, using subdivision technology, adjustable range: 0 - 650 degrees, more accurate control of the length of clothing, closed loop system to monitor the current position of the motor;

The sinker system is controlled by stepping motor, which can be adjusted according to different fabric, and can achieve a variety of needle picking and needle setting effects, and can be adjusted by left and right system;

Sari system computer program instructions, stepper motor control, 24 pull selection, adjustable range: 0-100; optional torque assisted Lola, providing effective force for thick cloth products.

Color changing system 2*8 yam in the side of 4 guide rails, can be in any position switch bar yarn (2*8 standard);

Stitch: optional scissors clip, initial device;

Control system:

 1. screen uses LCD industrial display, and the transmission mode adopts USB and network. A large number of flower files can be stored at the same time, and can be used at any time according to production needs;

2. monitor screen: can display all kinds of work parameters and the degree of knitting line value, and in the machine running at any time to adjust, to maximize the convenience of operation and save time;

3. plate making system and control system for independent research and development, the software part of the upgrade is convenient, for free configuration;

4. multi language operating version: support Chinese, English and other language versions, but also according to the needs of customers to set the required language;

Power single-phase 220V/ three-phase 380V, using advanced CMOS technology, in the power failure instant memory and recovery function;

It can knit basic knitting (Siping, single-sided etc.), multi-color jacquard, intarsia no specification (intarsia), twisted flowers, pick holes and weft tissue. Suitable for silk and silk, silk, wool, acrylic, synthetic fiber blended yarn and other raw materials, knitting sweaters and scarves, hats, hosiery and clothing accessories, specializing in the production of 3D is mainly used for shoe.





14G、5G 、6G 、7G、8G、9G、10G、11G、12G、14G G、15 G、16G、 3.5.7

Knitting width

36 ,52,66,72,80inch

Knitting system

Single carriage with three system; Single carriage with three system,Double carriage with single system.

Knitting function

Knit, miss, tuck, transfer, pointel , intarsia, jacquard, apparent or hide shaping and other regular or irregular patterns

Knitting speed

Controlled by servo-motor with 32 sections optional, max speed reach 1.5M/S


Controlled by servo-motor racking within 2 inches and with fine adjusting function

Stitch density

Controlled by stepping motor, 32 section stitch selectable adjustable scope supported by subdivision technology: 0-650, the stitch of the knitwear can be accurately controlled.


The transfer can is compose designed , single or double cam system all can transfer together or separately. Also one cam do transfer, another cam system for knitting, which will achieve high production.

Sinker system



controlled by stepping motor, adjustable to different knitwear, up to be various results of shaping and patterns.

Take-down system

Computer programs instruction, stepper motor control and 32-stagetension selection with an adjustable range between 0-100

comb device(C series)

Choose close U type compose needle hook, this special compose yarn hook with activity release theorem ,which will reliable to pick up yarn or release yarn .Zero waste yarn comb.

Color-changing system

2×8 yarn feeders at the single side of 4 guide rails, shiftable on any needle position.

Protection system

The machine will automatically alarm if yarn-breaking, knots, floating yarn, rewind, end of knitting, fail of racking, needle breakage, error programming occur, also set up the safety auto-lock protect device.

Control system

1. LCD industrial display, Can display various parameters, which can be adjustable during operation.

2. USB memory interface, System memory 1G and More than 2000 samples can be stored

3. Free design system is visual and easy to understand and software upgrade free of charge.


4.Support multi-language operation as Chinese and English, Spanish, Russian etc.

Network function

Has network interface, enable remote-monitoring via network, and connecting with ERP system.


Single-phase 220V/three-phase 380V,adopt advanced CMOS technology, having memorizing function at power shock stop. 800-1200w per unit


01-机器组成 拷贝02-展会

Adopting industrial LCD, graphic interface, color display. On working condition, parameters like weaving pieces, finished pieces, time, velocity, Roller, mesh number, yarn nozzle etc, could be all displayed clearly on the screen. When running, you can adjust parameters freely. This is the most convenient and time-saving device. All you need to do is just focusing on the fabric and inputting the command, and then all the parameters and pattern types could be changed.

Linear velocity of head can reach 1.5m/s. The stroke can be adjusted according the weaving width. Fast response, accurate location can avoid the invalid movement and increase the production efficiency. Each system is  equipped .
