Collar Knitting Machine

1. This series of models includes a single head and three systems.
2. Digital technology is adopted to realize the stitch transfer, tuck, and knitting actions of the flat knitting machine. Scissors clip device and bottom plate lifting device are optional.
3. The high-position roller system, the pulling position is closer to the needle plate tooth mouth, which ensures the high-quality roll control of the fabric.
4. The standard configuration of active yarn feeder greatly reduces the yarn feed resistance.
5. Infrared cloth roll detection system is equipped as standard, which can more effectively prevent the high roller from rolling cloth.
6. Equipped with infrared probe system to prevent the protection of knitting needles more effectively.
Availability:
Quantity:





衣领机


SPECIFICATION, GAUGE AND TECHNICAL PARAMETER



Gauge

14G、5G 、6G 、7G、8G、9G、10G、11G、12G、14G G、15 G、16G、 3.5.7

Knitting width

36 ,52,66,72,80inch

Knitting system

Single carriage with three system; Single carriage with three system,Double carriage with single system.

Knitting function

Knit, miss, tuck, transfer, pointel , intarsia, jacquard, apparent or hide shaping and other regular or irregular patterns

Knitting speed

Controlled by servo-motor with 32 sections optional, max speed reach 1.5M/S

Racking

Controlled by servo-motor racking within 2 inches and with fine adjusting function

Stitch density

Controlled by stepping motor, 32 section stitch selectable adjustable scope supported by subdivision technology: 0-650, the stitch of the knitwear can be accurately controlled.

Transfer

The transfer can is compose designed , single or double cam system all can transfer together or separately. Also one cam do transfer, another cam system for knitting, which will achieve high production.

Sinker system





controlled by stepping motor, adjustable to different knitwear, up to be various results of shaping and patterns.

Take-down system

Computer programs instruction, stepper motor control and 32-stagetension selection with an adjustable range between 0-100

comb device(C series)

Choose close U type compose needle hook, this special compose yarn hook with activity release theorem ,which will reliable to pick up yarn or release yarn .Zero waste yarn comb.

Product introduction:

1. This series of models includes a single head and three systems.

2. Digital technology is adopted to realize the stitch transfer, tuck, and knitting actions of the flat knitting machine. Scissors clip device and bottom plate lifting device are optional.

3. The high-position roller system, the pulling position is closer to the needle plate tooth mouth, which ensures the high-quality roll control of the fabric.

4. The standard configuration of active yarn feeder greatly reduces the yarn feed resistance.

5. Infrared cloth roll detection system is equipped as standard, which can more effectively prevent the high roller from rolling cloth.

6. Equipped with infrared probe system to prevent the protection of knitting needles more effectively.

01-机器组成 拷贝

02-展会

03-包装出货


04-培训
